KUPSupply 320mA
Zennio KUPSupply 320mA, ZPSU320, KNX power supply 320 mA, 29 V DC
| Manufacturer: | Zennio |
|---|---|
| Product no.: | 030300ZPSU320 |
Available
3 products in stock
Produktinformationen
Description
Zennio KUPSupply 320mA (ZPSU320) is a KNX universal power supply with 29 V DC auxiliary output and up to 320 mA output current. Designed for larger KNX installations, DIN rail mounting (4.5 TE).
Show more
Show less
Variants Properties
Technical data
| Weight: | 0.03 kg |
|---|---|
| Actuator Type: | Power Supply |
| Country of Origin: | Spain |
| Horizontal pitch (HP): | 4.5 |
| Output Current: | 0.32 A |
Show more
Show less
Downloads
Show more
Show less
Complementary products
More information
The Zennio KUPSupply 320mA is a KNX universal power supply designed for KNX installations with increased power demand. It provides a stable supply for the KNX system and an additional 29 V DC auxiliary output.
The maximum output current is 320 mA, making it suitable for larger KNX installations. The auxiliary voltage enables flexible system integration.
The power supply supports an input voltage of 110–240 V AC at 50/60 Hz and is designed for DIN rail mounting. With a width of 4.5 modular units, it offers a robust solution for installation in distribution boards.
- KNX universal power supply
- 29 V DC auxiliary output
- Maximum current 320 mA
- Input voltage 110–240 V AC, 50/60 Hz
- DIN rail mounting, 4.5 TE
